ID | Coordinates* | Neighboring genes | Expression (4–6, 7–8, 9–10, 11–12, 13–14, 15–16) |
Strongest annotations | Order |
---|---|---|---|---|---|
VT0837 | chr2L 1664946–1667142 (2196 bp) | chinmo, CR44603 |
weak |
brain primordium broad, brain broad, ventral nerve cord broad | VDRC |
Annotations
stage | annotation term | intensity |
---|---|---|
4-6 | not active | 0 |
7-8 | not active | 0 |
9-10 | not active | 0 |
11-12 | brain primordium broad | 1 |
13-14 | brain broad | 1 |
13-14 | ventral nerve cord broad | 1 |
15-16 | brain broad | 1 |
15-16 | ventral nerve cord broad | 1 |
Whole-slide images
No image data available.
Neighboring genes
gene ID | gene name | distance | links |
---|---|---|---|
FBgn0086758 | chinmo | overlapping | BDGP FlyBase iFly |
FBgn0265814 | CR44603 | 38926bp downstream | BDGP FlyBase |
FBgn0011570 | cpb | 39956bp upstream | BDGP FlyBase iFly |
FBgn0031356 | CG17660 | 42186bp upstream | BDGP FlyBase |
FBgn0266311 | CR44976 | 43506bp upstream | BDGP FlyBase |
Sequence
tcgtgacaaatgctgtctggaacaattcgatatatatatatatgtatatatatattatgcatatataaccataatgtagtcaacctctttttgttgcgacttgtgggcgtctggaagtgcaaaagaaattcaatttcttccaacctctttcgctttgtctttggtttattatttgtgggatttcaattgctttcataatcatttgacattttgtgggtaaattaataaggttgttttgtttcggattttatttcaatatttgcgtgggcgatgtgtaatggtcacgataaaaatatacagacttttaatgcgggggcttggtttcgatgaaagttgctcggatatttctgttattacttttaaatatgattaatgctggctcgaaattattaaatataacatgcaaatactttttcgtgtattttccttgtattaatccaagtaaccactgttttgcatacaaattctgaccttcaaagcgctaatcttttgacaaaatccataaatttaaagaaaactcttcctctcacttattccgctcgcttttatgtgaatgaaaataattttatgcaaaacccagatacgcacacacacacacacaaagtgtgagaaagctctgagtatctgtgtctgtgagtcatgtaaaaaaaaaagtaaaataaaagaaaagaaaaggcggacggagaaagaaaaaaccgaaaaaagtgaaatgaaatcaaatttatcttgaacttgaaaaatgaaaatgaagacatcgaagaccgtcgacaatgtttaacgttttatggcctctgttgttgtaaaattgtctcgtttaacatttattggatttcatgatacttttaaagactctttatctcagcagaaatgtacgaacagaattaaatactaattatttattaataattgcgctagcatagtgcaattaatttgatactcgtattttattattattatttctgtgtccgcttgttaatgtcagctggctcaaagtcaactaaaatatatatgtacatacgttcgactttgaaacgctcaaactgcaataacaaatgattgaagcaactcgtatttttgcaagggggatttcgcgaaggggttaactgcgcaaaagaacattgaatgcacacaaaatgtgttttaatgagataatcgcggagacaaaaaatgggtggaaaaaaaaattaatcgtgacaacaatcgtggcgtcaactgaatagcggccaaaaataacccagagtacatgcgaatatattaccatacatatatatgtctggggattggggatcggcgagaataagtggataatgcatgtgcaaaaagttgctgggttgcaccgccaataagagagcacaaagtttgagctaaattttaaatagccactcgtcatttggagacttttaattagtctagcatggccagatttaattggataaaatatgagtgtttaaaacacgcgccagatttattgcacagaatgtagtttatatttgctcagaaaaatagaaaatacatatatatattatttgctaaaattctgtatctatgccaagtatctagcctaagcagtatcaattaaaatcagccaatgcattcattattaaatgtcaaatatcgtagtggcaatcgagacgaaaacaaattctaaacgcgcttccgtatataaacagaaacccagcaacaaattcgacgtcatcagatgaagtcaaatgaattgcggataaataaagaggcgaataaaatgacataatagagcaaataaatatgcatacatatataaatactcctctctaaaaatgggtaaataaataatttagaatgaaaaaaatagtattaaatttaaaatttaagatacaagagaaaactaatttacgggcccagacaaagtgatccactaagttggcaaatgcttctgtatctctgccattgtatccctatctgcctttgtatctgtatctgcgctcgcactcgtatctgcggtctaactgtttttttttgcagctcttgctctcctcttattattatgtattagcattattatttacccgcctctgtttttttttttttttgtggaagcagcgtggaatgagagattcgtggaattgggacacttgtgtgcagtgccagcgaattgttgttgtgtctgtttcaaatattttttccgctgtttgcttccccgttttctcggctttctttc
PCR verification status
Line verified as correct.
